| The Texas Instruments 17AM
delivers the maximum protection in the |
 |
smallest package at an exsell price.... |
| The klixon 17AM Thermal
protector prevents overheating it s minithure, |
| snap-acting thermally
operated device that s a proven performer in |
| protection technology. |
| It protectsagainst overteating : |
|
| ⊙ Shaded pole motors. |
⊙ Recssed lighting fixtures. |
| ⊙ permanent split capacitor motrs. |
⊙ Bettery packs. |
| ⊙ Flourescent lighting ballast. |
⊙ Vacuum cleaners. |
|
| ⊙ HID ballast. |
⊙ Transformers. |
|
| ⊙ Automotive accessory motors, solenoids, PC
boards, ad otherapplications |
| Here`s why you should be usingTexas Instruments
17AM Thermal Protectors in your product |
| ⊙ Miniature size. |
⊙ Individually temperature cailbrated and
checked. |
| ⊙ Positive make ad break with Klixon snapaction
disc. |
| ⊙ Repeatable temperature perfomance over life. |
| ⊙ Gasketed steel case suitable for many
impregnation processes. |
| ⊙ Current and temperature sensitivity for
maximum design Flexibility. |
| ⊙ Wide selection of leads and insulating
sleeves. |
| ⊙ Same side or opposite side terminations. |
|
Leadership in quality, too. |
|
| The 17AM is automatically assembled, calibrated,
and checked omn modem, customer-designed equipment. |
| Texas instruments orea has had traditional
emphasis on quality. this is being reinforced by a corporate-widetrust |
| whitch reemphasizes the suppliers responsibility
and integrates modem statistical techniques in to the production |
| and quality-assuranceprocesses. As ongoing
inputs to the qurality-monitoring systems, over 12 different checks |
| are made during the manufacturing process.
Each 17AM temperature rating has a
bimetal disc speciflcally |
| manufactured for that rating. Each device is then
cali-brated and checked for opening tem-perature, this results in |
| optimum snap-acting open and reset characteristics
necessary to achieve consistent perfor-mance over the |
| required cycle life. |
)
